Guzzler® G2-0504N SapPuller 24 VDC Double Diaphragm Pump – Bosworth

P.O.A.

Compact 24V Brushless DC Guzzler Double-Diaphragm “G2-0504N” Pump. Twice the capacity of a single-diaphragm pump.

Bosworth Company Products are supplied by C&L Sales & Services P/L

Contact for Pricing



Description

MANUFACTURER: The Bosworth Company

Guzzler® G2-0504N SapPuller 24 VDC Double Diaphragm Pump – Bosworth Company

Compact 24V Brushless DC Guzzler Double-Diaphragm “G2-0504N” Pump. Twice the capacity of a single-diaphragm pump.

Features:

  • Ideal for vacuum production on maple sap collection lines
  • Up to 22 in of Hg vacuum
  • Efficient 24V Brushless DC motor can run for up to 40 hours on 2-12 VDC 60-amp hour batteries
  • Creates vacuum and transfers sap; no separator needed
  • Buna-N diaphragm and silicone umbrella valves
  • Features 1-1/4″ PVC Female inlet/outlet ports
  • Ships with two spare diaphragms



Performance

Dependent on Configurations

Max Pressure  10 psi / 0.7 bar
Lift   / Head 20.0 / 25.0 ft
6.1 / 7.6 m
Capacity
19.8 gpm / 74.9 lpm
Volume per stroke 1.10 qt / 1.00 l
Max Service Temp 140° F / 60° C

Guzzler® G2-0504N SapPuller Double Diaphragm Pump – Bosworth Company

Brand

Guzzler®
